Aluminum PCBs

Aluminum PCB substrate is a metal -based copper plate with good thermal conductivity, electrical insulation performance and mechanical processing performance.

Material: Aluminum core (Domestic 1060), Copper core, FR4 covering
Finish treatment: Immersion gold, OSP, Hard Gold, Immersion Silver, ENEPIG
Copper thickness: 0.5oz~ 10oz
Resin plugging vias & Buried vias
Impedance Controller Board

Aluminum PCBs – Technical specification
Feature Technical specification
Number of layers 1 - 4 layers standard
Technology highlights Aluminum plates and high heat -conducting insulating materials, high thermal conductivity, can be used as 8 -layer hybrid aluminum substrate
Solder Mask Green, Red, Yellow, Blue, White, Black, Purple, Matte Black, Matte green
Materials FR4 standard, FR4 high performance, Halogen free FR4, Rogers
Copper weights (finished) 0.5oz - 10.0oz
Minimum track and gap 0.075mm / 0.075mm
Finish Copper Weight 1-10oz
Maximum dimensions 610mm x 450mm; dependent upon laser drilling machine
Surface finishes available OSP, ENIG, Immersion tin, Immersion silver, Gold fingers
PCB Board Thickness 0.4-3.2mm
Via Process Tenting Vias, Plugged Vias, Vias not covered
Aluminum PCB

The aluminum PCB is a metal based copper clad laminate with good thermal conductivity, electrical insulation properties and mechanical processing properties. At this stage, the common aluminum PCB material is metal-based copper clad laminate (mainly aluminum-based, copper-based, and a small part of iron-based).

Metal aluminum-based copper clad laminate is a type of plate material made of electronic glass fiber cloth or other reinforcing materials impregnated with resin, single resin, etc. as an insulating adhesive layer, one or both sides covered with copper foil and made by hot pressing , Mainly used for processing and manufacturing  aluminum PCB substrates, widely used in televisions, radios, computers, computers, mobile communications, LED lighting and other products.

Aluminum pcb is a metal-based copper clad laminate with good heat dissipation function. Generally, a single-sided panel consists of three-layer structure, which are circuit layer (copper foil), insulating layer and metal base layer.

The aluminum PCB we generally call is a single sided aluminum PCB board, which has good thermal conductivity and is generally used in the LED industry.

Our 3 factories can produce more than 1000 different kinds of aluminum PCBs every day for sample and mass production. Total 4000 sqm/month.

The longgest can be reach 1.2m. and for V-cut also.
