Rigid printed circuit board

Most of the PCBs we usually see are rigid PCBs

Rigid PCB
Material: FR4
Finish treatment: Immersion Gold
Copper thickness: 1oz~ 2oz
Resin plugging vias & Buried vias
Impedance Controller Board

Rigid PCBs – Technical specification
Feature Technical specification
Number of layers 1-40 layer
Solder Mask Color Green, White, Blue, Black, Red, Yellow
Board Thickness 0.1mm - 0.8mm
Materials Polyimide, Polyester
Copper weights (finished) 0.5oz - 2.0oz
Minimum track and gap 0.075mm / 0.075mm
PCB thickness 0.40mm - 3.20mm
Maximum dimensions 610mm x 450mm; dependent upon laser drilling machine
Surface finishes available HASL - Hot air solder leveling
Lead - free HASL - RoHS
Immersion Tin - RoHS
Min Tracing/Spacing 3mil/3mil
Board Size Min 6*6mm, Max 406*610mm
Max. Array Size 1-40 layer
Solder Mask Color Green, White, Blue, Black, Red, Yellow
Max. Array Size 500*600mm / 250*1500mm(Special)
Min.board Size 1 *1mm
Max.Board thickness 0.23mm / 0.4mm(Special)
Min,Board thickness 0.075mm / 0.065 mm(Special)
Board thickness Tolerance ±0.03 mm
Rigid PCB:

Rigid PCB: Often used as a motherboard, it cannot be bent.

Most of the PCBs we usually see are rigid  PCBs, such as computer motherboards, graphics cards, memory and so on.

Rigid PCB is a type of printed circuit board and is the most manufactured PCB. Rigid PCB is a circuit board built on a rigid base layer that cannot be bent. Made of solid substrate material, it can effectively prevent the deformation of the circuit board. The most common rigid PCB is the computer motherboard. A motherboard is a multilayer PCB designed to distribute power from a power supply while allowing communication between all the components of the computer, such as the CPU, GPU, and RAM.

Rigid PCBs can be used anywhere the PCB itself needs to set shape and hold for the remainder of the life of the device. A rigid PCB can be anything from a simple single-layer PCB to an eight- or ten-layer multilayer PCB.
